Description

Technical Parameters

1. Working voltage: 415V, frequency: 50HZ.
2. Motor power: 1.5KW
3. System working pressure: 4-6MPa
4. Processing range: diameter 10-40MM, wall thickness 0.1-0.5MM,
5. Capacity: 5-10 seconds/piece
6. Mold change time: 5 minutes
7. Outline size：1200×600×1700mm
8. Weight: (approx.) 450 kg
9. Adopt a rigid mold spin-forming process. The flaring is formed once.
10. The size of the flaring diameter can be fine-tuned, and different pipe diameters with different molds.
11. Forming is cylinder-driven, speed is infinitely adjustable and easy to adjust.
12. Semi-automatic operation, manual picking and placing of material
