Description

Basic technical parameters:

Rated power: 60KW
Rated voltage: 380V
Rated temperature: 300℃
Number of temperature control zones: 1 zone {with timer alarm device}
Wiring method: Y
Frequency: 50HZ
Heating element: heated by stainless steel electric heating tube, the number is 54
Cylinder: ￠900X3.3 meters, made of 10mm iron plate
Cylinder movement method: manual
Cylinder sealing form: sealed with silicone rubber strip
Vacuum pump: 2X-30 rotary vane vacuum pump
Maximum processing length: 2.2 meters
Minimum inner diameter: ￠10.5mm
Maximum furnace loading: 2.2 meters X54 pieces
